Model No.: A+D
Wrench type quick connector
Quick connector is a connector that can connect or disconnect pipelines without tools. Quick connectors can be divided into: quick connector for air, quick connector for oxygen fuel gas, quick connector for gas and liquid, quick connector for oil pressure, quick connector for inert gas, quick connector for cooling water temperature oil and semiconductor quick connector. Here, we mainly introduce the quick coupling of handle type used in petrochemical industry.
The wrench type quick connector is divided into 9 types according to model: kjt-a type, B type, C type, D type, E type, F type, DC type, DP type and non-standard type, including 4 male heads of type A, E type, F type and DP type and 4 female heads of type B, C type, D type and DC type.
The wrench type quick connectors are divided into four categories according to materials: stainless steel wrench type quick connectors, brass wrench type quick connectors, aluminum alloy wrench type quick connectors and plastic wrench type quick connectors.
Manufacturing material: 304 316 aluminum alloy brass plastic
Nominal diameter: dn15-dn150mm
Nominal pressure: 16-64kg
Applicable temperature: - 20 ~ 150 ℃
Applicable medium: water, oil, gas and some corrosive liquids.
Scope of application: industrial, chemical, liquefied petroleum gas, vehicle and ship manufacturing equipment, etc.
Connection method: thread, welding, flange, quick connect, wrench type, etc.
1. Time saving and labor saving: when disconnecting and connecting the oil circuit through the quick connector, the action is simple, saving time and manpower.
2. Fuel saving: when the oil circuit is broken, the single valve on the quick connector can close the oil circuit, and the oil will not flow out, so as to avoid the loss of oil pressure.
3. Environmental protection: when the quick connector is broken and connected, the oil will not leak and protect the environment.
4. Equipment design is unique and convenient for transportation: large equipment or hydraulic tools that need to be carried easily can be disassembled and transported with quick connectors, and then assembled and used after arriving at the destination.
5. Economy: all the above advantages create economic value for customers.
Quick connector classification Description:
● type A: - one end is the joint embedded in the female head, and the other end is the internal thread port;
● type B: - one end is the concave pin for clamping the male head, and the other end is the external thread port;
● type C: - one end is a groove for clamping the male head, and the other end is a bamboo shaped hose connector;
● type D: one end is the groove for clamping the male head, and the other end is the internal thread port;
● type E: - one end is a connector embedded in the female head, and the other end is a bamboo shaped hose connection;
● type F: - one end is the joint embedded in the female head, and the other end is the external thread port;
● DC type: round female plug with fins that can catch the male head;
● DP type: quick fitting male plug, used with the parent body.
